A 1000 W strain gage (Rg) has a gage factor of 2.5

Q. A 1000 W strain gage (Rg) has a gage factor of 2.5. It is connected in the bridge as shown in figure. The strain gage is subjected with a positive strain of 400 mm/m. The output Vo (in mV) of the bridge is (up to two decimal places) .

Ans: 0.48-0.51
