Q. A broad gauge railway line passes through a horizontal curved section (radius = 875 m) of length 200 m. The allowable speed on this portion is 100 km/h. For calculating the cant, consider the gauge as centre-to-centre distance between the rail heads, equal to 1750 mm. The maximum permissible cant (in mm, round off to 1 decimal place) with respect to the centre-to-centre distance between the rail heads is
Solution:
Given :
R = 875 mm
Allowable speed = 100 kmph
Gauge length G = 1750 mm
![](https://www.gkseries.com/blog/wp-content/uploads/2023/08/Screenshot-471.png)
