Q. A test is conducted on a one-fifth scale model of a Francis turbine under a head of 2 m and volumetric flow rate of 1 m³/s at 450 rpm. Take the water density and the acceleration due to gravity as 10³ kg/m³ and 10 m/s², respectively. Assume no losses both in model and prototype turbines. The power (in MW) of a full sized turbine while working under a head of 30 m is _ (correct to two decimal places).

Ans: 28.85 – 29.25
