Q. A 7.5 m wide two-lane road on a plain terrain is to be laid along a horizontal curve of radius 510 m. For a design speed of 100 kmph, super-elevation is provided as per IRC: 73- 1980. Consider acceleration due to gravity as 9.81 m/s2. The level difference between the inner and outer edges of ...

Q. The space mean speed (kmph) and density (vehicles/km) of a traffic stream are linearly related. The free flow speed and jam density are 80 kmph and 100 vehicles/km respectively. The traffic flow (in vehicles/h, up to one decimal place) corresponding to a speed of 40 kmph is    Ans: 2000 ...

Q. A schematic flow diagram of a completely mixed biological reactor with provision for recycling of solids is shown in the figure. S0, S = readily biodegradable soluble BOD, mg/L Q, Qr, Qw = flow rates, m3/d X0, X, Xe, Xu = microorganism concentrations (mixed-liquor volatile ...

Q. At a small water treatment plant which has 4 filters, the rates of filtration and backwashing are 200 m3/d/m2 and 1000 m3/d/m2, respectively. Backwashing is done for 15 min per day. The maturation, which occurs initially as the filter is put back into service after cleaning, takes 30 min. It is ...

Q. A coal containing 2% sulfur is burned completely to ash in a brick kiln at a rate of 30 kg/min. The sulfur content in the ash was found to be 6% of the initial amount of sulfur present in the coal fed to the brick kiln. The molecular weights of S, H and O are 32, 1 and 16 g/mole, respectively. ...

Q. A flocculation tank contains 1800 m3 of water, which is mixed using paddles at an average velocity gradient G of 100/s. The water temperature and the corresponding dynamic viscosity are 30oC and 0.798×10-3 Ns/m2, respectively. The theoretical power required to achieve the stated value of G (in ...

Q. The total rainfall in a catchment of area 1000 km2, during a 6 h storm, is 19 cm. The surface runoff due to this storm computed from triangular direct runoff hydrograph is 1×108 m3. The Φindex for this storm (in cm/h, up to one decimal place) is                                       Ans: 1.5 ...

Q. A three-fluid system (immiscible) is connected to a vacuum pump. The specific gravity values of the fluids (S1, S2) are given in the figure. The gauge pressure value (in kN/m2, up to two decimal places) of 𝑝1 is Ans: -9.0 - -8.0 Sol:

Q. A group of nine piles in a 3 × 3 square pattern is embedded in a soil strata comprising dense sand underlying recently filled clay layer, as shown in the figure. The perimeter of an individual pile is 126 cm. The size of pile group is 240 cm × 240 cm. The recently filled clay has undrained ...

Q. The total horizontal and vertical stresses at a point X in a saturated sandy medium are 170 kPa and 300 kPa, respectively. The static pore-water pressure is 30 kPa. At failure, the excess pore-water pressure is measured to be 94.50 kPa, and the shear stresses on the vertical and horizontal ...

Q. A cable PQ of length 25 m is supported at two ends at the same level as shown in the figure. The horizontal distance between the supports is 20 m. A point load of 150 kN is applied at point R which divides it into two equal parts. Neglecting the self-weight of the cable, the tension (in ...

Q. A 6 m long simply-supported beam is prestressed as shown in the figure. The beam carries a uniformly distributed load of 6 kN/m over its entire span. If the effective flexural rigidity EI = 2×104 kNm2 and the effective prestressing force is 200 kN, the net increase in length of the ...
