Q. In the circuit shown below, assume that the comparators are ideal and all components have zero propagation delay. In one period of the input signal πππ = 6 sin(ππ‘), the fraction of the time for which the output OUT is in logic state HIGH is
![](https://www.gkseries.com/blog/wp-content/uploads/2023/08/image-45.png)
Sol:
The output represents X-NOR gate.
So, the given diagram can be simplified as
![](https://www.gkseries.com/blog/wp-content/uploads/2023/08/Screenshot-613.png)
0 β€ Vin < 3 happens for the period 0 to 30Β° and 150Β° to 180Β° the output is high for, 30 to 150Β° and 180Β° to 360Β° Total period gets high output = 300
![](https://www.gkseries.com/blog/wp-content/uploads/2023/08/Screenshot-614.png)
